Understanding Concrete Prep: The Essential Differences Between Acid Wash, Grinding, and Shot Blasting for Optimal CSP Levels

Proper concrete preparation is the foundation of any successful floor coating project. Whether you are installing epoxy flooring in a commercial warehouse or applying decorative flake floors in a residential garage, the surface must be prepared correctly to ensure adhesion, durability, and performance. Many people assume that cleaning concrete with an acid wash is enough, but this is far from the truth. To achieve the right surface profile and cleanliness, professionals rely on methods like grinding and shot blasting, which create specific Concrete Surface Profiles (CSP) essential for high-performance floor systems.

This post explains why concrete prep matters, the differences between acid washing, grinding, and shot blasting, and how CSP levels affect your floor coatings. We will also discuss why even new, uncontaminated concrete needs mechanical preparation to meet the standards required for industrial floor coatings, garage floor coatings, and other applications.

Concrete floor shot blasting for surface preparation

Close-up view of concrete floor being shot blasted to prepare surface for epoxy flooring

Why Concrete Preparation Is Critical for Floor Coatings

Concrete is a porous, alkaline material that can contain contaminants such as oils, curing compounds, dirt, and laitance (a weak, powdery layer on the surface). These contaminants prevent coatings like epoxy garage floors or seamless epoxy floors from bonding properly. Without proper prep, coatings may peel, blister, or wear prematurely.

The goal of concrete preparation is to:

• Remove contaminants and weak surface layers

• Create a rough surface profile for mechanical bonding

• Ensure the surface is clean and dry for coating application




The surface profile is measured using the Concrete Surface Profile (CSP) scale, which ranges from CSP 1 to CSP 9. This scale defines the roughness of the concrete surface, with CSP 1 being very smooth and CSP 9 being very rough.

Understanding Concrete Surface Profile (CSP) Levels

The CSP scale helps professionals select the right preparation method and coating system. Here’s a quick overview of the CSP levels:

• CSP 1: Very smooth, nearly flat surface (like a steel trowel finish)

• CSP 2: Slightly rough, light broom finish

• CSP 3: Medium broom finish, some texture

• CSP 4: Heavy broom finish or light grinding

• CSP 5: Medium grinding or light shot blasting

• CSP 6: Heavy grinding or medium shot blasting

• CSP 7: Very rough surface, heavy shot blasting

• CSP 8: Rough surface with exposed aggregate

• CSP 9: Very rough, deeply exposed aggregate surface




For most concrete floor resurfacing and chemical-resistant floors, a CSP between 3 and 6 is ideal. This range provides enough texture for coatings to bond without creating an overly rough surface that can trap air or cause uneven finishes.

Acid Washing: What It Does and Why It’s Not Enough

Acid washing uses a mild acid solution, typically muriatic acid, to etch the concrete surface. This process removes surface contaminants and opens the pores of the concrete slightly.

Pros of acid washing:

• Removes surface dirt and some contaminants

• Opens pores for better coating adhesion than untreated concrete

• Relatively low cost and easy to apply




Cons of acid washing:

• Does not create a sufficient surface profile (usually CSP 1 or 2)

• Fails to remove embedded contaminants or laitance fully

• Can leave residue that interferes with coatings if not rinsed properly

• Not suitable for new concrete that requires mechanical profile for bonding




Because acid washing only lightly etches the surface, it cannot replace mechanical methods like grinding or shot blasting. For durable floor coatings such as commercial epoxy flooring or West Michigan epoxy floors, acid washing alone will lead to poor adhesion and coating failure.

Grinding: Creating the Right Surface Profile

Grinding uses diamond abrasive pads or discs to mechanically remove the top layer of concrete. This method exposes fresh concrete and creates a consistent surface profile.

Advantages of grinding:

• Produces a controlled CSP level, typically between 3 and 6

• Removes contaminants, laitance, and weak surface layers

• Smooths out uneven surfaces and removes minor imperfections

• Ideal for preparing new, uncontaminated concrete for coatings




Grinding is essential even on new concrete slabs. Although the surface may look clean, it often has a smooth trowel finish (CSP 1 or 2), which is too smooth for coatings like metallic epoxy floors or slip-resistant flooring to adhere properly.

Grinding also allows a professional epoxy installer or epoxy floor contractor to tailor the surface profile to the specific coating system being applied.

Shot Blasting: Efficient Surface Preparation for Large Areas

Shot blasting propels small steel shot particles at high velocity onto the concrete surface. This method removes contaminants and creates a rough profile by fracturing the surface layer.

Benefits of shot blasting:

• Creates a uniform surface profile, usually CSP 3 to 7 depending on settings

• Removes laitance, dirt, and weak surface layers effectively

• Faster and less dusty than grinding for large commercial or industrial floors

• Ideal for industrial floor coatings and commercial epoxy flooring




Shot blasting is commonly used in warehouses, factories, and large garages where floor coating companies need to prep extensive areas quickly. It also helps expose aggregate for better mechanical bonding.

Grinding machine preparing concrete floor for epoxy coating

High angle view of grinding machine smoothing concrete floor surface for epoxy floor application

Why Even New Concrete Needs Grinding or Shot Blasting

New concrete slabs often have a smooth, dense surface due to steel troweling. This finish looks clean but is too smooth for coatings to bond well. Without mechanical preparation, coatings like basement floor coatings or custom epoxy floors will not adhere properly, leading to peeling or delamination.

Grinding or shot blasting removes the smooth surface layer and exposes the porous, rougher concrete underneath. This creates the necessary CSP level for strong mechanical adhesion.

Even if the slab is uncontaminated, mechanical prep is critical to:

• Remove any curing compounds or sealers left on the surface

• Create a consistent surface profile for coating adhesion

• Ensure long-lasting, durable floor coatings






Choosing the Right Preparation Method for Your Project

Selecting between acid washing, grinding, and shot blasting depends on several factors:

For Hudsonville MI epoxy flooring or Grand Rapids concrete coatings, professionals often combine methods. For example, they may acid wash first to remove surface dirt, then grind or shot blast to achieve the proper CSP.

Summary of Key Points

• Proper concrete prep is essential for successful epoxy flooring and concrete coatings.

• Acid washing only lightly etches the surface and does not create a sufficient profile for strong adhesion.

• Grinding and shot blasting mechanically remove contaminants and create the necessary CSP levels (3-6) for durable coatings.

• Even new, uncontaminated concrete requires grinding or shot blasting to prepare the surface.

• CSP levels range from 1 (smooth) to 9 (very rough), with most coatings needing CSP 3-6.

• Choosing the right prep method depends on the project size, concrete condition, and coating type.




If you want your slip-resistant flooring, chemical-resistant floors, or waterproof floor coatings to last, invest in proper concrete preparation. Working with a professional epoxy installer or trusted floor coating company ensures your floors receive the right prep for long-term performance.
